Features:
Certified with the Keymark – high technical standards.
Automatic adjustment according to external temperature and energy demand.
Water delivery: 65 ° C at + 5 ° C outdoor temperature, 60 ° C at - 15 ° C.
Domestic hot water ( DHW) accumulation at 60 ° C.
Quick configuration via USB port.
Diagnostics for fast start- up and maintenance.
Integrated ACUAZONE control – management of up to 32 zones ( underfloor heating, fan coils, radiators).
Compatible with Amazon Alexa, Google Assistant, and cloud services.
Integration via Modbus, BACnet, KNX, and other protocols.
Compliant with European and national grants and certifications ( HP Keymark, EKO SKLAD, Zelená Domácnostiam, BAFA, Superbonus…).
Included in the CYPE database for calculation and specification purposes.
Intuitive control and monitoring via the Comfort Home app.
Smart Grid protocol for optimal comfort and energy savings.
| Type | Outdoor Unit | Heating Capacity (kW) 7°C / T OUTLET 35°C | COP | Heating Capacity (kW) 7°C / T OUTLET 55°C | COP | Outdoor Unit Sound Pressure Level (dB(A)) | Refrigerant | Power Supply | Recommended circuit breaker | Energy Class |
|---|---|---|---|---|---|---|---|---|---|---|
| KHPS-MO 4 PRO HP | KHP-MO 18 DVR2 | 18 | 4,7 | 18 | 2,75 | 57,6 | R-32 | 3f/400V | 20A / type C | A+++/A++ |
| KHPS-MO 22 PRO HP | KHP-MO 22 DVR2 | 22 | 4,4 | 22 | 2,65 | 59,8 | R-32 | 3f/400V | 20A / type C | A+++/A++ |
| KHPS-MO 26 PRO HP | KHP-MO 26 DVR2 | 26 | 4,08 | 26 | 2,45 | 61,5 | R-32 | 3f/400V | 25A / type C | A+++/A++ |
| KHPS-MO 30 PRO HP | KHP-MO 30 DVR2 | 30,1 | 3,91 | 30 | 2,3 | 63,5 | R-32 | 3f/400V | 32A / type C | A+++/A++ |
User manual
Návod na obsluhu a inštaláciu SK - Aquantia Monobloc KHPS-MO Pro HP.pdfProduct sheet
Product Sheet - Aquantia Monobloc KHPS-MO Pro HP.pdfDeclaration of conformity
Declaration of Conformity - Aquantia Monobloc KHPS-MO Pro HP.pdfFor partners 1
